DOWSIL™ TC-6020

Compare
Applications
Twopart, 1 to 1 gray silicone elastomer and heat cure and room temperature cure for manufacturing flexibility, thermally conductive encapsulant/pottant for electronics providing protection from harsh environmental conditions and thermal management dedicated for power module, automotive control unit, etc..
Caracteristics
2 part / Viscosity : 10 640 mPas / Hardness : Shore A63 / Gray / Thermal conductivity : 2.72 W/m.K / Dielectric Strength : 24.1 KV/mm / Elongation : 20.6% / 24h at 23°C or 13min at 80°C
Property
Electronic silicone / Thermally conductive Encapsulant / 2 parts / addition RTV / Low viscosity / Excellent dielectric properties / UL 94 V-0
Dangerous. Observe safety precautions - For professional use only
See the different packaging

Variations

This product is not available online.Contact us
Name Code article Price Availability
DOWSIL™ TC-6020
20 kg Kit
DETC6020K20 Contact us
DOWSIL™ TC-6020
2 kg Kit
DETC6020 Contact us

Caracteristics

Application Methode Automatic, Manual
Curing Type Room Temperature Curing
Certification / Specification UL 94 V0, UL RTI 150
Chemistry / Technology Silicon
Brand DOWSIL
Product's associated market Electronics, E-Mobility
Color Grey
Hardness Class Medium Hard (Shore A61 - A80)
Hardness 63 Ashore
Electric Properties Electrically Insulating
Number of Component Bi Componant / 2 Parts
Maximum temperature (°C) 200 CELSIUS
Minimum temperature (°C) -45 CELSIUS
Thermal Conductivity (W/m⋅K) 2.72 WmK
Dynamic Viscosity (25°C) 10640 mPas
