DOWSIL™ 1-2620

Compare
Applications
DOWSIL™ 12620 formerly DOW CORNING® 12620, is a conformal coating for flexible and rigid circuit boards.
Caracteristics
Transparent / Viscosity: 150 mPa·s / 80 Shore A / Working time: 5 min / 60 min at 25°C (77°F) or 2 min at 60°C (140°F) / Registered UL 94 V-0, Mil Spec, IPC-CC-830B, UL 746-E and UL RTI 130
Property
Electronic silicone / Coating / Elastoplastic / One-part / HTV & RTV condensation / UV indicator / low viscosity. Download chemical equivalency certificates by clicking on the Homologation link opposite.
Dangerous. Observe safety precautions - For professional use only
See the different packaging
Request for quotation
Request for information
Contactez-nous par téléphone au 04 26 680 680

Variations

This product is not available online.Contact us
Name Code article Price Availability
DOWSIL™ 1-2620
454 g Bottle
DE2620-454 Contact us
DOWSIL™ 1-2620
3,6 kg Drum
DE2620-36 Contact us
DOWSIL™ 1-2620
18,1 kg Drum
DE2620-18 Contact us
DOWSIL™ 1-2620
199,5 kg Drum
DE2620-200 Contact us
DOWSIL™ 1-2620
175 ml Cartridge
DE2620-175 Contact us

Caracteristics

Application Methode Automatic
Curing Type Room Temperature Curing
Certification / Specification IPC CC 830B, MIL-1-46058C, UL 746E, UL 94 V0, UL RTI 130
Chemistry / Technology Silicon
Dielectric Strength (kV/mm) 22 kV_mm
Brand DOWSIL
Product's associated market Aeronautics, Electronics
Color Clear
Number of Component Mono Componant / 1 Part
Maximum temperature (°C) 200 CELSIUS
Minimum temperature (°C) -45 CELSIUS
Dynamic Viscosity (25°C) 150 mPas
