Airtech update his brochure dedicated to the composite market
Airtech, world leader in vacuum accessories and peripherals for the processing of composite materials
Airtech offers the widest and most complete range of vacuum bagging products.
Whether in :
- vacuum bag,
- Tear-off tissues,
- release films,
and all the accessories you will need for the realization of your composite part,…
The Airtech range will meet your expectations.
Airtech has updated its infusion brochure and has selected from its wide range of products to meet all the problems associated with this type of application, as an example:
- Vacuum bag,
- Micro-perforated release film,
- adhesive tape, release films,
- peel plies, and seals
in order to make a successful infusion whatever the shape, dimensions or complexity of the piece to be made.
| References | Maximum use Temperature | Elongation | Tensile strength |
|---|---|---|---|
Vacuum bag |
|||
| Airtech Big Blue | 120°C | 350 % | 21 Mpa |
| Airtech Ipplon KM 1300 | 212°C | 450 % | 48 Mpa |
Perforated release films |
|||
| Airtech DAHLAR BAG 125 | 140°C | 400 % | 65 Mpa |
| Wrightlon 3900 | 157°C | 500 % | 41 Mpa |
| References | Maximum use Temperature | Carrier type | Adhesive Type |
|---|---|---|---|
|
Tapes |
|||
| Airtech Airhold 10 CBS (white) | 60°C | Cloth | Rubber |
| Airtech Teflease MG2 (brown) | 260°C | PTFE | Silicone |
| Airtech Flashbreaker 1 (Blue or orange) | 204°C | Polyester | Silicone |
| Films Adhésifs Démoulants | |||
| Airtech Tooltec A005 (Thickness : 125µm) | 204°C | PTFE Coated Fibreglass | Silicone |
| Airtech Toolwright 5 (Thickness : 125µm) | 260°C | Extruded Fluoropolymer | Silicone |
| Airtech Tooltec CS5 (Thickness : 165µm) | 260°C | PTFE | Silicone |
| References | Maximum use Temperature | Fibre type | Weight | Colour |
|---|---|---|---|---|
|
Peel ply |
||||
| Airtech Econostich G | 190°C | Polyester | 85 g/m² | White / Black Tracer |
| Airtech Econolease | 204°C | Nylon silicone coated | 61 g/m² | Light blue |
| Airtech Release Ease 234 TFP | 288°C | PTFE Coated Fibreglass | 60 g/m² | Brown |
| References | Maximum use temperature | Colour | Base material | Tack |
|---|---|---|---|---|
|
Sealant Tapes |
||||
| Airtech cordon butyl Airseal 2 | 120°C | Black | Synthetic rubber | Good tack |
| Airtech cordon butyl Airseal 2 super tacky | 120°C | Black | Synthetic rubber | High tack |
| Airtech cordon butyl AT200Y | 204°C | Yellow | Synthetic rubber | High tack |
More informations :
Do you need information about Airtech ? Contact our technical department on +33 426 680 680 or fill in our contact form.
Download the Airtech brochure dedicated to composite market :
